Details

Type: 2.4G RF controller
Availability: In Stock

Description

JM-DST-01 single color dimmer

Name	led dimmer	Output	3 Channel
Output current	<4A/CH	Output power	12V:<144W;24V:<288W

Product Description

1: PWM signal touch remote led dimmer;
2: Can control all kinds of constant voltage DC12V-24V LED strips, led modules and other low voltage led light;
3: RF2.4GHZ Wireless control, High speed, more stability;
4: Beautiful white color design,
5: Can dimming brightness and some flash models;

6: 1 remote a control 3 controllers even more

Details Image

Function

Model No.	Model Effect	Remark
1	Static Color	Brightness and speed are adjustable
2	Strobe Flash
3	Fade In And Fade Out
4	Blasting Flash

Installation

A: 1. You need 1 remote and 3 receivers with led light.
2. Pair receiver A to Zone 1, pair receiver B to Zone 2, pair receiver C to Zone 3
3. Press button 1 to select Zone 1 receiver and light, UP and Down for dimming, Left and right for modes, Turn on/off.
4. Press button 2 to select Zone 2 receiver and light, UP and Down for dimming, Left and right for modes, Turn on/off.
5. Press button 3 to select Zone 3 receiver and light, UP and Down for dimming, Left and right for modes, Turn on/off.
6. Press button all to select all zone receivers and lights, UP and Down for dimming, Left and right for modes, Turn on/off.

JM-DST-02 CCT Controller

Product Description

1: PWM signal touch remote LED CCT Controller, 6A/CH.
2: Can dimming brightness of CCT LED Light and some flash models;

3: 1 remote an control 3 receivers even more.

Details Imange

Function

Model NO.	Mode Effect	Model NO.	Mode Effect
1	Warm Color Fade In And Fade Out	4	Warm Color Strobe Flash
2	Cool Color Fade In And Fade Out	5	Cool Color Strobe Flash
3	Warm Color & Cool Color Cross Fade	6	Warm Color & Cool Color Strobe Flash

JM-DST-03 RGB Controller

Product Description

1: PWM signal touch remote LED RGB Controller;
2: Can dimming brightness of RGB LED Light and some color models;
3: 1 remote an control 3 controllers even more.

Details Image

Function

Model NO.	Model Effect	Model NO.	Model Effect
1	3 Colors fade in and fade out	5	White color fade in and fade out
2	Seven colors jumping change	6	White color fade in and fade out
3	Seven colors jumping change	7	Green color fade in and fade out+ flash 3 times
4	Seven color fade	8	Blue color fade in and fade out+ flash 3 times
9	Auto-cycle mode

JM-DST-04 RGBW Controller

Product Description

1: PWM signal touch remote LED RGBW Controller;
2: Can dimming brightness of RGBW LED Light and some color models;
3: 1 remote an control 3 receivers even more.

Details Image

Function

Model NO.	Model Effect	Model NO.	Model Effect
1	3 colors jumping change	7	White color fade in and fade out
2	3 Colors fade in and fade out	8	Red color fade in and fade out+ flash 3 times
3	Seven colors jumping change	9	Green color fade in and fade out+ flash 3 times
4	Seven Colors Flash	10	Blue color fade in and fade out+ flash 3 times
5	Seven color fade	11	White color fade in and fade out+ flash 3 times
6	7 Colors fade in and fade out	12	Auto-cycle mode
